UHMWPE Washers

Tecafine® HDPE and LDPE

  • Broad chemical compatibility
  • Especially good wear resistance
  • Exceptional low temperature impact strength
  • Low moisture absorption

Available in all thickness from .005 to .125 with or without adhesive backing
Go To Our Catalog To Find A Standard Size Washer And Request A Quote

Property ASTM Test Units Metric (US) .030″ .060″ .125″
Density D792 gm/cc 0.93 0.93 0.93
Tensile Strength @ Yield D638 MPa(psi) 23(3300) 20(2964) 22(3227)
Tensile Strength @ Break D638 MPa(psi) 53(7740) 49(7056) 44(6373)
Elongation @ Break D638 % 460 463 466
Youngs “E” Modulus D638 MPa (psi x 105) 725(1.05) 731(1.06) 672(0.97)
Hardness Shore “D” D2240 65 65 65
Abrasion Resistance
Relative Solution Viscosity D4020 dl/gm 2.3 – 3.5 2.3 – 3.5 2.3 – 3.5
Coefficient of Friction
Static 0.16 0.16 0.16
Dynamic 0.14 0.13 0.14
Property ASTM Test Units Metric (US): Density D792 gm/cc
.030″: 0.93
.060″: 0.93
.125″: 0.93

Property ASTM Test Units Metric (US): Tensile Strength @ Yield D638 MPa(psi)
.030″: 23(3300)
.060″: 20(2964)
.125″: 22(3227)

Property ASTM Test Units Metric (US): Tensile Strength @ Break D638 MPa(psi)
.030″: 53(7740)
.060″: 49(7056)
.125″: 44(6373)

Property ASTM Test Units Metric (US): Elongation @ Break D638 %
.030″: 460
.060″: 463
.125″: 466

Property ASTM Test Units Metric (US): Youngs “E” Modulus D638 MPa (psi x 105)
.030″: 725(1.05)
.060″: 731(1.06)
.125″: 672(0.97)

Property ASTM Test Units Metric (US): Hardness Shore “D” D2240
.030″: 65
.060″: 65
.125″: 65

Property ASTM Test Units Metric (US): Abrasion Resistance
.030″:
.060″:
.125″:

Property ASTM Test Units Metric (US): Relative Solution Viscosity D4020 dl/gm
.030″: 2.3 – 3.5
.060″: 2.3 – 3.5
.125″: 2.3 – 3.5

Property ASTM Test Units Metric (US): Coefficient of Friction
.030″:
.060″:
.125″:

Property ASTM Test Units Metric (US): Static
.030″: 0.16
.060″: 0.16
.125″: 0.16

Property ASTM Test Units Metric (US): Dynamic
.030″: 0.14
.060″: 0.13
.125″: 0.14
